Design Capabilities |
 |
|
 Design
and development capabilities
Our engineering team uses the latest
CAD/CAM technology to design tooling. It reduces Lead time and also
create earliest visibility of new product to manufacturing team.
Design and development setup includes :
- CAD (Unigraphics NX4) for model
building, product design
- CAE (Hyperworks Suite with LS-DYNA
post processor
- Tool Design (Unigraphics-Progressive
die wizard)
- Strip layout (Optimization of strip
layout to derive best yield)
The new developments are effectively
managed across all areas of organization through our APQP (Advance
Product Quality Planning) system.
With expertise in tool designing Supreme has achieved higher level of
accuracy. In normal course we follow.
Product Development
Process at Supreme
CAD Data |
|
Generate MID Surface |
|
Meshing |
|
Auto Tipping |
|
Formability Analysis |
|
Tooling Concept |
|
Strip layout to get best yield |
|
|
|
|
